This adaptor is needed when the various pressure-/support sleeves of the KL-0039-.. Series are to be used in conjunction with the press frames of the KL-0039-.. Series.
Technical data
Diameter milled slot of piston rod
20,5 mm
Contents (Qty of pieces)
1
VDE certified
No
1000 V insulated
No
Target groups
Automotive
Construction and commercial vehicles
Agriculture
Drive type
hydraulic
mechanical
Customs tariff number
82055980
Total length
45 mm
Outer diameter
65 mm
External thread
2¼"-14 UNS
Inner diameter (2)
30 mm
Mounting diameter
46mm
Short text
• For mounting the pressure / support sleeves or KL-0039-..
• In combination with a press frame of the KL-0039 series
